RP 206E Remote Panel
The RP 206E Remote Panel, a twin engine remote panel for Marine Pro 200 and 400 series controllers, is a high-resolution marine display for engine alarming and visualization. Designed for manoeuver and wing stations. Out of the box the RP 206E includes operator-selectable inbuilt languages, fuel consumption measurements, unit selection, event log and many more features that vessel operators appreciate at sea. Cyber Security certified.
The RP 206E Remote Panel, a twin-engine remote panel for Marine Pro 200 and 400 series controllers, is a high-resolution marine display for engine alarming and visualization. Designed for manoeuver and wing stations. Out of the box the RP 206E includes operator-selectable inbuilt languages, unit selection, event log and many more features that vessel operators appreciate at sea.
The ultra-crisp touch screen, colour graphics, and fully protected front and rear provide the best readability and reliability under all weather conditions. Capable of displaying up to two engines with a complex set of sensor data.
The RP 206E auto-configures to any 200 and 400 series controllers, which truly reduces installation and maintenance costs. Like the RP 220E, the RP 206E is capable of monitoring two DCUs or Engines. Compared to the RP 210E remote panel, the RP 206E is a monitor only remote panel for when one wants to maintain operational security.
The panel connects to DCUs using only a standard Ethernet cable, and will automatically “find” any DCUs that are connected to the network. No configuring, no setup, no hassle. Additionally, when connected, the RP 206E will update itself with any DCU configuration changes automatically, providing seamless consistency across all panels. Using the brightness-adjustable touch screen, the operator gets full overview and control of the equipment, exactly as operating the DCU engine controller locally at the engine. The operator can select the language at the RP 206E independently of the DCU. There is no practical limit to how many RP 206E remote panels that can be connected to one engine controller.
Note! A Basic Harness Kit (P/N: 1006946) including one prewired Deutsch DT-connector with a 2 m power cable and three sealing blind plugs for easy installation is available and if needed, this must be ordered separately.
At a glance:
Compact twin-engine remote panel
Sun readable, colour touch screen, all glass design
Configurable graphics
Alarm and event log for all engines
Camera support
Inbuilt troubleshooting and support aid
Marine Pro auto configuration – lowest commissioning cost
Connects to DCUs using only a standard Ethernet cable
Why choose the DCU 410E:
Feature-rich enabling improved operational efficiency
Capable of displaying up to two engines
Monitor-only functionality maintains operational security
Durable, rugged and sealed for use in arduous conditions
Compatible with all 200 Series and 400 Series DCUs
No practical limit to distance or number of remote panels connected
SKU: 1006478
Category: Remote Panels
Tags: IP56, Marine Pro 200, Remote Panel, Touchscreen
